Drawing Navigator automatically builds a database from CAD PDF drawings and adds modern conveniences like search and quick access to legacy drawings. Next to every drawing see the bill-of-materials and where-used links for quick access.

Launch tags:Windows•Productivity•Tech

Launch Team

Flowstep — Generate real UI in seconds

Generate real UI in seconds

Promoted

Maker

I have been a mechanical design engineer for nine years and every place I have worked has had difficult to use legacy drawings. This was personal software for quite some time before I polished it up a bit and thought that other engineers in similar positions might benefit from this as much as I have. The latest version uses OCR to pull important information from the drawings automatically and build a useable database in far less time than manually sifting through the drawings and setting up spreadsheets to track the hierarchy.
