No compromise on quality Ever higher performance for your motors ensured by : The factory settings, which provide a high quality drive from the very first time the power is turned on The integration of Standard (U/f), Performance (sensorless flux vector control, or SVC) and Pump/Fan (quadratic profile Kn�) control profiles High dynamic performance on acceleration as well as on braking Excellent speed regulation on machine load surges Reduced noise and maintenance Designed for easy fitting and wiring of the drive : Easy access angles Numerous, easy to identify markings Fast detection and protection against motor current peaks (common in motor switching and catch on the fly applications) Perfect integration of single-phase 240 V model into the electrical network thanks to its built-in EMC filter Save time on wiring Easy access to all the wiring and settings on the front panel Easy access angles Only one screwdriver needed for all connections Save time on programming A navigation button for easy menu access: configure your application parameters in just a few clicks A three-level menu structure Reference Mode: In local operation (On/Off buttons) and for speed adjustment and display Monitoring Mode: For displaying parameters (create your own menu) Configuration Mode: For configuring your applications and settings Save time on commissioning The drive can be configured before it is received (by the distributor), during storage (by the storekeeper) or during fitting before the electrical enclosure is powered up for the first time No adjustment is required and there is a quick start guide for immediate setup Ease of programming: Work in the language of your choice and, from November 2009, download the SoMove software workshop free on www.schneider-electric.com Bluetooth option for downloading or accessing settings via PC or mobile phone for greater ease of use
