Technical Specifications (PJ20F-E & PA50F-E Models)
Review the specific data for our 20Ah and 50Ah LFP pouch cells below. Our engineers are fully equipped to design custom battery pack solutions tailored to your specific voltage platforms based on these cells.
Specification |
Model: PJ20F-E |
Model: PA50F-E |
Nominal Capacity |
20 Ah |
50 Ah |
Energy Density |
164 Wh/kg |
167 Wh/kg |
Max. Continuous Charge Rate |
2C |
2C |
Max. Continuous Discharge Rate |
2C |
3C |
Max. Pulse Charge Rate |
4C |
3C |
Max. Pulse Discharge Rate |
4C |
4C |
Operating Temperature |
-30 +55 |
-30 +55 |
Cycle Life (1C/1C) |
3000 cycles |
3000 cycles |
Dimensions (T W H, mm) |
9.2 90 231 |
12.8 161 232 |
