Engineered for extreme performance, we offer high-rate, high-energy, wide-temperature lithium batteries across multiple chemistries, including LiFePO₄, NMC, and LCO, for global B2B clients.

This is the 6th launch from LiTrue. View more

40Ah Solid-State Anode-Free Cell

Launched this week

40Ah Solid-State Anode-Free Cell 495Wh/kg

PE40N-EF is a 40Ah solid-state anode-free lithium cell with 3.85V rated voltage, 495Wh/kg energy density, 3C continuous discharge, and -43°C to 55°C operating range.

40Ah Solid-State Anode-Free Cell gallery image

Free

Launch tags:Batteries

Launch Team

Viktor.comAn AI coworker that actually does the work

Promoted

Be the first to comment

Previous LiTrue Launches

25Ah Anode-Free Solid-State Cell25Ah 480Wh/kg Anode-Free Solid-State Cell OEM Factory Direct

Launched on July 1st, 2026

100Ah High C-Rate Cell100Ah High C-Rate LFP Prismatic Battery Cell

Launched on June 17th, 2026

17.5Ah High C-rate LFP Pouch Cell17.5Ah 6C/20C High C-rate LFP Pouch Battery Cell

Launched on June 9th, 2026

High C-rate Long Cycle Life LFP CellHigh C-rate Long Cycle Life LFP Pouch Battery Cell

Launched on May 13th, 2026

View all LiTrue launches

Forum Threads

p/litrue

•

1mo ago

High C-rate Long Cycle Life LFP Pouch Battery Cell

Technical Specifications (PJ20F-E & PA50F-E Models)

Review the specific data for our 20Ah and 50Ah LFP pouch cells below. Our engineers are fully equipped to design custom battery pack solutions tailored to your specific voltage platforms based on these cells.

Specification	Model: PJ20F-E	Model: PA50F-E
Nominal Capacity	20 Ah	50 Ah
Energy Density	164 Wh/kg	167 Wh/kg
Max. Continuous Charge Rate	2C	2C
Max. Continuous Discharge Rate	2C	3C
Max. Pulse Charge Rate	4C	3C
Max. Pulse Discharge Rate	4C	4C
Operating Temperature	-30 +55	-30 +55
Cycle Life (1C/1C)	3000 cycles	3000 cycles
Dimensions (T W H, mm)	9.2 90 231	12.8 161 232

Hybrid agricultural machinery and electric two-wheelers
