Flat Pattern Bend Calculator is a small tool that helps you to calculate the shape of the sheet metal part before it is formed with less efforts. Flat Pattern Bend Calculator is completely free and be updated based on users feedback. Use cases: Flat pattern representations allow you to create a simplified representation of a sheet metal part in the flattened state. This application is useful for engineer who need a simple tool to calculate the flat pattern of the sheet metal part, which can be formed to 3D part. It is also essential for indie inventors, mechanical engineers, etc. to help you draw manually even when there is a power outage or no computer. Advantages: • Simple use • Offline work, fast launch Features: • Calculate flat pattern • Show detail drawing • Export to .dxf file extensions

Flat Pattern Bend Calculator

Calculate the shape of the sheet metal part to form to part

Calculate the shape of the sheet metal part to form to part
